Because it is designed for micro ATX and Mini-ITX boards, the B4-mATX Mesh keeps the overall build compact without forcing you into the tightest small-form-factor layouts. Choose the motherboard size that matches your needs, from a minimal Mini-ITX setup to a more expandable micro ATX configuration.
The case ships without a power supply, so you can pick a unit that matches the wattage and efficiency your components require. This gives you full control over the build and makes it easy to reuse a PSU you already own when upgrading.
This white Mini Tower case suits home and office desktops, compact gaming systems and first-time builders working with micro ATX or Mini-ITX hardware who want a tidy, light-coloured setup.
| Brand | LIAN LI |
|---|---|
| Form factor | Mini Tower |
| Model name | Lian Li B4-mATX Mesh White (G99.B4W.00) |
| Product colour | White |
| Material | Steel |
| Type | PC |
| Side window | No |
| Illumination | No |
| Suitable for | Gaming |
| Bullet Points | <ul> <li>Compact 21.3L mATX case with broad compatibility.</li> <li>Supports M-ATX / Mini-ITX, 358mm 4-slot GPUs, and 140mm ATX PSUs.</li> <li>Supports up to 360mm radiators with SFX PSU, or 240mm with ATX PSU.</li> <li>Up to 168mm CPU cooler clearance, or 162mm with side fan bracket.</li> <li>Includes 2 pre-installed 120 ×120 ×15mm slim top fans.</li> <li>Supports up to 9 fans across top, side, bottom, rear, and front.</li> <li>Removable top bracket simplifies CPU 8-pin routing and fan setup.</li> <li>Removable front bracket allows easier large GPU installation.</li> <li>Supports both horizontal and vertical layouts.</li> <li>Optional Vertical AeroDeck adds up to 3 ×120mm or 2 ×140mm fans for GPU cooling.</li> </ul> |
| Cable management | Yes |
| Long Description | Lian Li B4-mATX Mesh. Form factor: Mini Tower, Type: PC, Product colour: White. Supported power supply form factors: SFX, ATX. Front fans diameters supported: 120 mm, Side fans diameters supported: 120,140 mm, Rear fans diameters supported: 120 mm. Supported HDD sizes: 2.5,3.5", SSD form factor: 2.5". Width: 191 mm, Depth: 420 mm, Height: 288 mm |
| Maximum PSU length | 140 |
| Top fans installed | 2x 120 mm |
| Number of 2.5" bays | 1 |
| Number of 3.5" bays | 1 |
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
| Warranty | 1 years |
| EAN | 4718466023278 |
| Built-in display | No |
|---|
| Maximum CPU cooler height | 162 |
|---|
| SSD form factor | 2.5" |
|---|---|
| Capacity | 21.3 |
| Supported HDD sizes | 2.5/3.5 |
| Maximum graphics card length | 358 |
|---|
| Built-in speaker(s) | No |
|---|
| Combo headphone/mic port | Yes |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| On/off button | Yes |
|---|
| Power supply included | No |
|---|---|
| Supported power supply form factors | ATX/SFX |
| Noise level | 30.3 dB |
|---|---|
| Fan speed | 0 - 1800 |
| Maximum airflow | 64.2 |
| Anti-dust filter | Yes |
| Maximum air pressure | 2.4 |
| Liquid cooling installed | No |
| Liquid cooling capability | Yes |
| Rear fans diameters supported | 120 |
|---|---|
| Side fans diameters supported | 120/140 |
| Side radiator sizes supported | 240/280/360 |
| Front fans diameters supported | 120 |
| Bottom fans diameters supported | 120/140 |
| Supported motherboard form factors | micro ATX/Mini-ITX |
| Number of rear fans supported (max) | 1 |
| Number of side fans supported (max) | 3 |
| Number of front fans supported (max) | 1 |
| Number of bottom fans supported (max) | 3 |
| Width | 191 mm |
|---|---|
| Depth | 420 mm |
| Height | 288 mm |
| Product Net Weight | 6.1 kg |
