Besides 2.4 and 5 GHz, the router adds a 6 GHz band that older devices cannot use, so it stays less crowded. 320 MHz wide channels let a compatible device reach top speed, while Multi-Link Operation combines the bands into a steadier link. A single band delivers up to 5764 Mbit/s.
Gamers and tech-savvy families with new Wi-Fi 7 devices and a fast fibre connection. The gaming port, one-tap game prioritisation and Open NAT help in online play, while three-level AiProtection security and Smart Home Master subnetworks keep smart home and VPN traffic separate.
| Brand | ASUS |
|---|---|
| Product type | Tabletop router |
| Model name | 90IG0A30-MO9C00 |
| Product colour | Black |
| Firewall | Yes |
| Modulation | 4096-QAM/OFDMA |
| DHCP server | Yes |
| Media server | Yes |
| Warranty card | Yes |
| Parental control | Yes |
| System event log | Yes |
| Quick start guide | Yes |
| Dynamic DNS (DDNS) | Yes |
| Built-in FTP server | Yes |
| WAN connection type | RJ-45 |
| EAN | 4711387931851 |
| Processor cores | 4 |
|---|---|
| Processor frequency | 1500 GHz |
| Built-in processor | Yes |
| Internal memory | 1000 GB |
|---|
| Support Samba (storage) | Yes |
|---|
| Flash memory | 256 MB |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
|---|---|
| USB port | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 4 |
| Ethernet LAN data rates | 2500 Mbit/s |
| Ethernet LAN interface type | 2.5 Gigabit Ethernet |
| Ethernet WAN | Yes |
| SIM card slot | No |
| Port forwarding | Yes |
| Port triggering | Yes |
| Wake-on-LAN ready | Yes |
| 3G/4G USB modem compatibility | Yes |
| Wi-Fi standards | 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be) |
|---|---|
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| WLAN data transfer rate (max) | 9400 Mbit/s |
| Antenna design | External |
| Security algorithms | SSH/WPA/WPA2-Enterprise/WPA2-Personal/WPA3-Enterprise/WPA3-Personal/WPA-Enterprise/WPA-Personal/WPS |
| Antennas quantity | 6 |
| Bandwidth control | Yes |
| MU-MIMO technology | Yes |
| Network address translation (NAT) | Yes |
| WLAN data transfer rate (first band) | 688 |
| WLAN data transfer rate (third band) | 5764 |
| WLAN data transfer rate (second band) | 2882 |
| Firewall security | Maximum Firewall Keyword Filter : 64 Maximum Firewall Network Service Filter : 32 Maximum Firewall URL Filter : 64 |
|---|
| On/off switch | Yes |
|---|---|
| Reset button | Yes |
| WPS push button | Yes |
| AC adapter included | Yes |
|---|---|
| AC input voltage | 110 – 240 V |
| AC input frequency | 50/60 |
| Output voltage | 12 V |
| Power source type | AC |
| Output current | 2.5 |
| MAC address filtering | Yes |
|---|
| Cables included | LAN (RJ-45) |
|---|---|
| LED indicators | Power, LAN, WAN |
| DMZ support | Yes |
| VPN support | nstant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion Support Surfshark Support Nord VPN |
| Package type | Box |
| Quality of Service (QoS) support | Yes |
| Width | 320 mm |
|---|---|
| Depth | 179 mm |
| Height | 191 mm |
| Weight | 764 g |
According to the manufacturer, up to 2500 square feet. Real results depend on walls and placement, and you can add an AiMesh node if needed.
There is no SIM slot, but according to the manufacturer the router supports a 3G/4G USB modem connected to its USB port.
All ports run at 2.5 Gbit/s: one WAN for the internet and three LAN ports, one of which is the gaming port. For more devices, add a network switch.
