The 1/2.7-inch CMOS sensor records at 2960 × 1668 and up to 30 frames per second. The 2.8 mm lens covers 108.4° horizontally, 60° vertically and 127.1° diagonally, so one camera can watch a whole yard or warehouse room. 120 dB WDR, BLC and HLC handle backlight and headlights, while 3D noise reduction keeps the picture clean at dusk.
The camera has a built-in illuminator with two light sources: according to the manufacturer, infrared and warm light each reach up to 50 m. Infrared gives a discreet black-and-white image, while warm light provides a colour picture in the dark. Smart IR adjusts the illuminator so close objects are not overexposed, and a minimum illumination of 0.0005 lx lets the camera see in near darkness.
As a WizMind series camera, it runs Xinghan large-scale vision models and deep-learning algorithms. IVS functions cover intrusion and tripwire detection, human and vehicle classification and people counting; the manufacturer also lists face detection, video metadata and AcuPick. Because alarms are triggered by people or vehicles rather than leaves and shadows, false alerts are reduced.
The camera can record on its own to a microSD card of up to 1 TB or to network-attached storage (NAS), so a recorder is not always required. H.265 and H.264 with SMART H.265+, ROI and SVC keep archives small. Supported protocols include RTSP, HTTPS and IEEE 802.1x, live view is available in the mobile app for Android and iOS, and up to 20 users can be set up.
The camera is powered over PoE+ (IEEE 802.3at), with ePoE and 12 V DC also supported. Typical consumption is 4.2 W and the maximum is 13.3 W. It mounts on a ceiling, wall or pole, and the camera module pans 0–360° and tilts 0–80°. The metal housing weighs 530 g, measures 122 mm across and 105.5 mm high, and operates from −40 to 60 °C.
Private houses, stores, warehouses and industrial yards that need to watch a wide area at short and medium distance. The wide 2.8 mm lens suits a driveway, a car park or a warehouse floor, people counting is useful for retail spaces, and with an operating range down to −40 °C a cold winter is no obstacle. The white housing matches light facades and eaves.
| Brand | DAHUA |
|---|---|
| Form factor | Turret |
| Product colour | White |
| Housing material | Metal |
| Type | IP security camera |
| Manual | Yes |
| Mirror | Yes |
| LED type | IR |
| Pan range | 0 - 360 |
| Frame rate | 30 |
| Night vision | Yes |
| Dynamic range | 120 |
| Mounting type | Ceiling/Wall/Pole |
| White balance | Auto/Manual/Natural/Outdoor/Regional custom/Street lamp |
| Detect distance | 61.6 |
| Number of users | 20 |
| Video streaming | Yes |
| Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Observe distance | 24.6 |
| Progressive scan | Yes |
| Streaming method | Multicast |
| Tilt angle range | 0 - 80 |
| Total megapixels | 5 |
| Digital watermark | Yes |
| Identify distance | 6.2 |
| Alarm input/output | Yes |
| Fixed focal length | 2.8 |
| Recognize distance | 12.3 |
| Alarm input channels | 1 |
| Minimum illumination | 0.0005 |
| Alarm output channels | 1 |
| Night vision distance | 50 |
| Video motion detection | Yes |
| Maximum aperture number | 1.6 |
| People counting function | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Video compression formats | H.264/H.264B/H.264H/H.265/M-JPEG |
| Number of illumination LEDs | 2 |
| Region of Interest (ROI) encoding | Yes |
| Human and vehicle targets classification | Yes |
| EAN | 6937552409989 |
| Maximum resolution | 2960 x 1668 |
|---|
| RAM capacity | 2048 |
|---|
| Compatible memory cards | MicroSD (TransFlash) |
|---|---|
| Maximum memory card size | 1000 GB |
| Built-in HDD | No |
| ROM capacity | 4096 |
| Storage temperature (T-T) | -40 - 60 |
| Network access storage (NAS) | Yes |
| Day/night mode | Yes |
|---|---|
| Video recording | Yes |
| Number of cameras | 1 |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Camera shutter speed | 1/3 - 1/100000 |
| Closest focusing distance | 1 |
| Lens viewing angle, diagonal | 127.1 |
| Lens viewing angle, vertical | 60 |
| Lens viewing angle, horizontal | 108.4 |
| Built-in microphone | Yes |
|---|---|
| Audio input channels | 1.0 |
| Audio output channels | 1.0 |
| Audio formats supported | G.711 µ-law/G.711 A-law/G.723/G.726/PCM |
| Card reader integrated | Yes |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Ethernet interface type | Fast Ethernet |
| Wi-Fi | No |
|---|---|
| Bluetooth | No |
| Connectivity technology | Wired |
| Networking standards | IEEE 802.1x/IEEE 802.3at |
| Supported network protocols | IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P |
| Mobile operating systems supported | Android/iOS |
|---|---|
| HTTPS encryption | Yes |
| Gain control type | Auto/Manual |
|---|
| Power consumption (typical) | 4.2 W |
|---|---|
| Power consumption (max) | 13.3 W |
| Power source type | PoE+, DC |
| DC output voltage | 12 |
| Operating temperature (T-T) | 0 – 40 – 60 °C |
|---|---|
| Noise reduction | Yes |
| Angle of rotation | 360 |
| Noise reduction technology | 3D noise reduction |
| Signal-to-Noise Ratio (SNR) | 56 |
| International Protection (IP) code | IP67 |
|---|---|
| Protection features | Dustproof/Waterproof |
| Smart IR | Yes |
| Sensor type | CMOS |
| Built-in light | Yes |
| Optical sensor size | 1/2.7 |
| Placement supported | Outdoor |
| Highlight Compensation (HLC) | Yes |
| Back Light Compensation (BLC) | Yes |
| Quality of Service (QoS) support | Yes |
| Intelligent Video Surveillance (IVS) system features | Intrusion/Tripwire |
| Diameter | 122 mm |
|---|---|
| Weight | 530 g |
| Length | 105.5 |
Yes, it supports the PoE+ standard IEEE 802.3at and ePoE, and it can also run on 12 V DC. Maximum consumption is 13.3 W.
According to the manufacturer, infrared and warm light reach up to 50 m. With warm light, colour images are possible at night.
Yes, it has a microSD slot (up to 1 TB) and supports recording to network-attached storage (NAS). A card is not included.
Yes, it is designed for outdoor use: the housing is rated IP67 and operates from −40 to 60 °C.
