The Intel Celeron N5095 is a quad-core processor with a 2.0 GHz base clock and bursts up to 2.9 GHz. It supports Intel VT-x and VT-d virtualisation and AES-NI encryption, which protects data without slowing the system down. Virtualization Station runs Windows and Linux virtual machines, Container Station handles Docker, LXD and Kata containers, and Linux Station gives you a Linux desktop. The 8 GB of memory can grow to 16 GB.
The two M.2 2280 PCIe Gen 3 slots take NVMe SSDs that can serve as a cache, as a separate SSD storage pool or as part of Qtier auto-tiering. Alternatively you can fit a Google Edge TPU, which speeds up face and object recognition in QuMagie photo albums. Image recognition also benefits from the Intel OpenVINO AI engine built into the processor.
Intel UHD Graphics supports hardware video decoding and real-time transcoding. The HDMI output drives a display at up to 4K: connect a TV or monitor and you can watch stored films and photos without a computer, or show a virtual machine desktop directly on the screen. That lets the TS-664 double as a simple workstation.
The two 2.5GbE ports work over existing CAT5e cabling and reach up to 5 Gbit/s when trunked. Two 10 Gbit/s USB 3.2 Gen 2 ports suit backups to external drives, and two USB 2.0 ports can take, for example, a UPS. The PCIe Gen 3 x2 slot accepts a 10GbE or 5GbE network card, a QM2 card or a USB 3.2 Gen 2 card.
Block-based snapshots record the state of the system and let you roll a volume, folder or single file back to an earlier point. Hybrid Backup Sync copies data to another NAS, a server or the cloud for a 3-2-1 strategy, and QuDedup removes duplicate data at the source. Windows PCs are backed up with NetBak Replicator and Macs with Time Machine.
Small businesses that want one device to cover file serving, backup and a few virtual machines. Families and media fans who play films from the NAS on a TV over HDMI and sort photos with AI recognition. Home lab builders running Docker containers and Linux apps. With six bays there is room for a RAID 5 or RAID 6 array plus a hot spare.
| Brand | QNAP |
|---|---|
| Model name | TS-664 |
| Product colour | Black/Bronze |
| Type | NAS |
| Buzzer | Yes |
| Intel 64 | Yes |
| Snapshot | Yes |
| Disk scan | Yes |
| Hot spare | Yes |
| System log | Yes |
| DHCP server | Yes |
| Idle States | Yes |
| Chassis type | Tower |
| Device class | Small & Medium Business |
| Disk roaming | Yes |
| Fan diameter | 90 |
| RAID rebuild | Yes |
| Share folder | Y |
| Bad block scan | Yes |
| Number of fans | 2 |
| Backup function | Yes |
| Dynamic DNS (DDNS) | Yes |
| Built-in FTP server | Yes |
| Management protocols | SNMP V2, V3 |
| Online RAID expansion | Yes |
| Online RAID migration | Yes |
| Access Control List (ACL) | Yes |
| Number of M.2 (M & B) slots | 2 |
| Operating relative humidity (H-H) | 5 - 95 |
| Share folder access right management | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Warranty | 3 years |
| EAN | 4711103082317 |
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel® Celeron® |
| Processor model | N5095 |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor frequency | 2 GHz |
| Processor boost frequency | 2.9 GHz |
| CPU configuration (max) | 1 |
| Number of processors supported | 1 |
| Internal memory | 8 GB |
|---|---|
| Internal memory type | DDR4 |
| Memory slots | 2 |
| Memory form factor | SO-DIMM |
| Hot-swap drive bays | Yes |
|---|---|
| Storage drives installed | No |
| Storage temperature (T-T) | -20 - 70 |
| Installed storage drive type | No |
| Storage drive sizes supported | 2.5/3.5/M.2 |
| Supported storage drive types | HDD & SSD |
| Total installed storage capacity | 0 |
| Number of storage drives supported | 6 |
| Supported storage drive interfaces | M.2, Serial ATA III |
| On-board graphics card model | Intel® UHD Graphics |
|---|
| Flash memory | 4000 MB |
|---|
| HDMI ports quantity | 1 |
|---|---|
| HDMI version | 2.1 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB port | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Ethernet LAN data rates | 10/100/1000/2500 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| USB copy function | Yes |
| Wake-on-LAN ready | Yes |
| Security algorithms | FIPS 140-2/HTTPS/SNMPv2/SNMPv3/SSH |
|---|
| Operating system installed | QNAP QTS |
|---|---|
| Operating system version | 5.0.0 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite/Mac OS X 10.11 El Capitan/Mac OS X 10.12 Sierra/Mac OS X 10.13 High Sierra/Mac OS X 10.14 Mojave/Mac OS X 10.15 Catalina/Mac OS X 10.15.3 Catalina/Mac OS X 11.0 Big Sur/Mac OS X 12.0 Monterey/Mac OS X 13.0 Ventura |
| Linux operating systems supported | Ubuntu 14.04 |
| Other operating systems supported | Solaris 10 |
| Server operating systems supported | Windows Server 2008/Windows Server 2012 R2/Windows Server 2016/Windows Server 2019 |
| Windows operating systems supported | Windows/Windows 10/Windows 10 Education/Windows 10 Education x64/Windows 10 Enterprise/Windows 10 Enterprise x64/Windows 10 Home/Windows 10 Home x64/Windows 10 IOT Core/Windows 10 IoT Enterprise/Windows 10 Pro/Windows 10 Pro x64/Windows 10 x64/Windows 11 |
| On/off switch | Yes |
|---|---|
| Reset button | Yes |
| Backup button | Yes |
| Power consumption (typical) | 44.02 W |
|---|---|
| AC input voltage | 100 – 240 V |
| Fan voltage | 12 |
| Power supply location | External |
| External power adapter | Yes |
| Power consumption (sleep) | 23.22 |
| Number of power supply units | 1 |
| Power supply unit (PSU) capacity | 120 |
| Operating temperature (T-T) | 0 – 40 °C |
|---|---|
| RAID levels | 0/1/10/5/50/6/JBOD |
| Cooling type | Active |
| Enhanced Intel SpeedStep Technology | Yes |
| Cables included | AC/LAN (RJ-45) |
|---|---|
| LED indicators | HDD/LAN/Power/Status/USB |
| Package type | Box |
| RAID support | Yes |
| iSCSI support | Yes |
| Backup features | Cloud/iSCSI LUN |
| Browser supported | Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox |
| S.M.A.R.T. support | Yes |
| Jumbo frames support | Yes |
| Multilingual support | Yes |
| Maximum RAM supported | 16 |
| Supported file systems | ext3/ext4/FAT32/HFS+/NTFS |
| Intel Trusted Execution Technology | No |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Width | 235 mm |
|---|---|
| Depth | 226 mm |
| Height | 168 mm |
| Weight | 2.9 kg |
| Product Net Weight | 2.9 kg |
No. The NAS ships without drives: the six bays take 2.5″ and 3.5″ SATA HDDs and SSDs, and the M.2 slots take 2280 NVMe SSDs. A power cable and a LAN cable are in the box.
There are two memory slots supporting up to 16 GB of DDR4 SO-DIMM. 8 GB comes installed.
HDMI lets you connect the NAS directly to a TV or monitor to play stored video at up to 4K, or to display a virtual machine or the Linux Station desktop without a separate computer.
Yes. Macs back up with the built-in Time Machine and Windows PCs with NetBak Replicator. SMB/CIFS, AFP and NFS are supported for file sharing.
