Eight hot-swap bays take 2.5″ and 3.5″ SATA drives. Supported levels are RAID 0, 1, 5, 6, 10, 50, 60 and JBOD, along with hot spare variants in which a standby drive takes over automatically when another fails. Arrays can be expanded or migrated while online. When the bays fill up, you can attach TR-004 or TR-002 expansion enclosures, or one TL-D800C, TL-D400S or TL-D800S JBOD.
Two 10GbE SFP+ ports connect the NAS to a fast switch or workstation and speed up large files, backups and video transfers. Two 2.5GbE RJ-45 ports fit an ordinary network. The ports support Port Trunking and failover, so if one link drops, traffic continues over another. The SFP+ ports need an SFP+ transceiver or a DAC cable.
The Annapurna Labs AL324 is a quad-core 64-bit ARM Cortex-A57 processor running at 1.7 GHz. QNAP emphasises its energy efficiency, and typical consumption is 50.9 W. Memory is 4 GB of DDR4 at 2400 MHz on a SO-DIMM. With a single slot, an upgrade means swapping in a larger module, up to 16 GB. Three fans keep the noise level at 19.6 dB, according to the manufacturer.
This model has no built-in M.2 slots, but the PCIe Gen 2 slot takes a QNAP QM2 card that adds M.2 SATA or NVMe SSDs for caching and Qtier auto-tiering. The same slot also accepts a 5GbE or 2.5GbE network card, a USB 3.2 Gen 2 card or a QNAP Wi-Fi 6 card that lets the NAS create its own wireless network.
Up to 256 block-based snapshots per NAS and 64 per volume let you restore files that were deleted or damaged by ransomware. File sharing works over SMB/CIFS, AFP and NFS, Qsync keeps files identical across devices, and Hybrid Backup Sync backs up to another NAS, a remote server or OneDrive, Google Drive and Dropbox. HybridMount and VJBOD Cloud link the NAS with cloud storage.
Small and medium businesses that need eight drives of capacity and 10GbE connectivity without a separate network card. Media producers, architects and design studios whose large files benefit from a fast network. Offices where the NAS runs day and night, and an efficient ARM processor with quiet cooling matters more than virtual machine performance.
| Brand | QNAP |
|---|---|
| Model name | TS-832PX |
| Product colour | Aluminium/Black |
| Remotely operated | Yes |
| Type | NAS |
| Buzzer | Yes |
| Snapshot | Yes |
| Hot spare | Yes |
| System log | Yes |
| DHCP client | Yes |
| DHCP server | Yes |
| Chassis type | Tower |
| Device class | Small & Medium Business |
| Disk roaming | Yes |
| Fan diameter | 120 |
| RAID rebuild | Yes |
| Bad block scan | Yes |
| Fan diameter 2 | 60 |
| Number of fans | 3 |
| Backup function | Yes |
| Link aggregation | Yes |
| Number of screws | 56 |
| Dynamic DNS (DDNS) | Yes |
| Built-in FTP server | Yes |
| Management protocols | SNMP |
| Web-based management | Yes |
| Online RAID expansion | Yes |
| Online RAID migration | Yes |
| Remote administration | 256-bit AES, FIPS 140-2, HTTPS, SNMP, SSH |
| Access Control List (ACL) | Yes |
| Built-in BitTorrent client | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Operating relative humidity (H-H) | 5 - 95 |
| Share folder access right management | Yes |
| Warranty | 2 years |
| EAN | 4713213518182 |
| Processor manufacturer | Annapurna Labs |
|---|---|
| Processor family | Annapurna Labs |
| Processor model | AL324 |
| Processor cores | 4 |
| Processor frequency | 1.7 GHz |
| Processor architecture | ARM Cortex-A57 |
| Number of processors supported | 1 |
| Internal memory | 4 GB |
|---|---|
| Internal memory type | DDR4 |
| Memory slots | 1 |
| Memory clock speed | 2400 MHz |
| Memory form factor | SO-DIMM |
| Drive bay locking | Yes |
|---|---|
| Hot-swap drive bays | Yes |
| Storage drive capacity | 0 |
| Storage drive interface | Serial ATA III |
| Storage drives installed | No |
| Storage temperature (T-T) | -20 - 70 |
| Installed storage drive type | No |
| Storage drive sizes supported | 2.5/3.5 |
| Supported storage drive types | HDD & SSD |
| Total installed storage capacity | 0 |
| Number of storage drives supported | 8 |
| Supported storage drive interfaces | Serial ATA II, Serial ATA III |
| Flash memory | 512 MB |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
|---|---|
| USB port | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Ethernet LAN data rates | 100/1000/10000/2500 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| USB copy function | Yes |
| Wake-on-LAN ready | Yes |
| Fiber ports quantity | 2 |
| Fiber optic connector | SFP+ |
| Security algorithms | 256-bit AES/FIPS 140-2/HTTPS/SNMP/SSH |
|---|
| Operating system installed | QNAP Turbo System |
|---|---|
| Operating system version | 5.0.0 |
| Mac operating systems supported | Mac OS X 10.0 Cheetah/Mac OS X 10.1 Puma/Mac OS X 10.10 Yosemite/Mac OS X 10.11 El Capitan/Mac OS X 10.12 Sierra/Mac OS X 10.13 High Sierra/Mac OS X 10.14 Mojave/Mac OS X 10.15 Catalina/Mac OS X 10.15.3 Catalina |
| Linux operating systems supported | CentOS 7.0/Ubuntu 14.04 |
| Other operating systems supported | IBM AIX 7.1/IBM AIX 7.2/Solaris 10 |
| Server operating systems supported | Windows Server 2008 R2/Windows Server 2012/Windows Server 2012 R2/Windows Server 2016/Windows Server 2019 |
| On/off switch | Yes |
|---|---|
| Reset button | Yes |
| Backup button | Yes |
| Power consumption (typical) | 50.86 W |
|---|---|
| AC input voltage | 100 – 240 V |
| AC input frequency | 50 – 60 Hz |
| Fan voltage | 12 |
| Output current | 3.5 |
| Power supply location | Built-in |
| WLAN adapter supported | Yes |
| Power consumption (sleep) | 27.949 |
| Number of power supply units | 1 |
| Power supply unit (PSU) capacity | 250 |
| Noise level | 19.6 dB |
|---|---|
| Operating temperature (T-T) | 0 – 40 °C |
| RAID levels | 0/1/10/10+HS/5/5+S/50/6/6+HS/60/JBOD |
| Cooling type | Active |
| Load balancing system | Yes |
| Cables included | AC/LAN (RJ-45) |
|---|---|
| LED indicators | HDD/LAN/Status/System/USB |
| Package type | Box |
| RAID support | Yes |
| iSCSI support | Yes |
| Backup features | Cloud/iSCSI LUN/USB drive |
| Browser supported | Apple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox |
| S.M.A.R.T. support | Yes |
| Third-party support | Yes |
| Jumbo frames support | Yes |
| Maximum RAM supported | 16 |
| Supported file systems | ext3/ext4/FAT32/HFS+ |
| Width | 329.3 mm |
|---|---|
| Depth | 279.6 mm |
| Height | 188.2 mm |
| Weight | 7.05 kg |
| Product Net Weight | 7.05 kg |
No. The NAS ships without drives; the eight bays take 2.5″ and 3.5″ SATA HDDs and SSDs. A power cable and a LAN cable are in the box.
Yes. M.2 SSDs are added with a QNAP QM2 expansion card in the PCIe Gen 2 slot, after which SSD caching and Qtier auto-tiering are available.
Up to 16 GB. There is one memory slot holding the supplied 4 GB DDR4 SO-DIMM, which is replaced when upgrading.
There is no built-in Wi-Fi, but a QNAP Wi-Fi 6 (802.11ax) network card can be installed in the PCIe slot.
