The chassis is just 44 mm tall, one rack unit, 430.5 mm wide and 295.5 mm deep, or 327.5 mm including the handles. According to Synology it fits a two-post or wall-mount rack, so there is no need to invest in costly rail kits. Three 40 mm fans provide active cooling, the operating range is 0–35 °C and the unit weighs 4.38 kg.
The dual-core, four-thread AMD Ryzen Embedded R1600 runs at 2.6 GHz and boosts up to 3.1 GHz. Its 2 GB of DDR4 memory is ECC, which detects and corrects memory errors before they can corrupt stored files. In the manufacturer measurements, sequential throughput reaches 601 MB/s read and 516 MB/s write.
The two 1GbE RJ-45 ports support failover and load balancing: if one link drops, the other carries on. For a faster network there is an easily accessible slot for the Synology E10G22-T1-Mini module, which adds a 10GbE port. Wake-on-LAN starts the NAS over the network, and the USB 3.2 Gen 1 port takes an external drive.
The bays accept 2.5-inch and 3.5-inch SATA drives, both hard drives and SSDs, and they are hot-swappable. Supported RAID levels are 0, 1, 5, 6 and 10, plus JBOD. Internally DSM uses the Btrfs and ext4 file systems, and external drives formatted as exFAT, FAT32, NTFS, HFS+ or ext3 can be read as well. Drives are chosen separately.
The NAS runs Synology DSM 7.1 and is managed in a browser (Chrome, Firefox, Edge, Safari). Supported protocols include SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, SSH, SNMP and VPN (PPTP, OpenVPN, L2TP). It handles up to 2048 users and 1024 shared folders, with permissions set through ACLs. License-free backup tools and a surveillance application come with the system.
Small businesses and branch offices with a rack or wall cabinet that need one device for file sharing, sync between locations and PC backups. Also home lab owners who want a low 1U chassis, ECC memory and the option to move to 10GbE later, and small surveillance deployments.
| Brand | SYNOLOGY |
|---|---|
| Model name | RS422+ |
| Product colour | Black |
| ECC | Yes |
| Type | NAS |
| Chassis type | Rack (1U) |
| Device class | Home & Home Office |
| Fan diameter | 40 |
| Share folder | 1024 |
| Number of fans | 3 |
| Rack mount kit | Yes |
| Backup function | Yes |
| Number of users | 2048 |
| Operating altitude | 0 - 5000 |
| Quick installation guide | Yes |
| Access Control List (ACL) | Yes |
| Operating relative humidity (H-H) | 8 - 80 |
| Share folder access right management | Yes |
| EAN | 4711174724475 |
| Processor manufacturer | AMD |
|---|---|
| Processor family | Ryzen Embedded |
| Processor generation | AMD Ryzen Embedded R1000 Series |
| Processor model | R1600 |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor frequency | 2.6 GHz |
| Processor boost frequency | 3.1 GHz |
| Internal memory | 2 GB |
|---|---|
| Internal memory type | DDR4 |
| Hot-swap drive bays | Yes |
|---|---|
| Storage drives installed | No |
| Storage temperature (T-T) | -20 - 60 |
| Installed storage drive type | No |
| Storage drive sizes supported | 2.5/3.5 |
| Supported storage drive types | HDD & SSD |
| Storage relative humidity (H-H) | 5 - 95 |
| Number of storage drives supported | 4 |
| Supported storage drive interfaces | Serial ATA |
| On-board graphics card model | Not available |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
|---|---|
| USB port | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Ethernet LAN data rates | 1000 Mbit/s |
| I/O ports | Console Port |
| Wake-on-LAN ready | Yes |
| Expansion ports quantity | 1 |
| Supported network protocols | SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, and VPN (PPTP, OpenVPN, L2TP) |
|---|
| Operating system installed | DSM |
|---|---|
| Operating system version | 7.1 |
| On/off switch | Yes |
|---|---|
| Reset button | Yes |
| AC input voltage | 100 – 240 V |
|---|---|
| AC input frequency | 50 – 60 Hz |
| Operating temperature (T-T) | 0 – 35 °C |
|---|---|
| RAID levels | 0/1/10/5/6/JBOD |
| Cooling type | Active |
| Cables included | AC |
|---|---|
| LED indicators | Yes |
| RAID support | Yes |
| Browser supported | Google Chrome, Firefox, Microsoft Edge, Safari 13 and later, and Safari (iOS 13.0 and later) on iPad, Chrome (Android 11.0 and later) on tablets |
| Supported file systems | BTRFS/exFAT/ext3/ext4/FAT32/HFS+/NTFS |
| Width | 430.5 mm |
|---|---|
| Depth | 295.5 mm |
| Height | 44 mm |
| Weight | 4.38 kg |
| Product Net Weight | 4.38 kg |
No, the NAS ships without drives. It takes four 2.5-inch or 3.5-inch SATA drives, either hard drives or SSDs.
Yes, with the Synology E10G22-T1-Mini network module. It goes into the dedicated slot and adds a 10GbE port; the module is not included.
The unit has 2 GB of DDR4 ECC memory. The manufacturer does not specify the number of memory slots or the maximum capacity.
Yes. According to Synology, the 1U chassis fits two-post and wall-mount racks. Depth is 295.5 mm, or 327.5 mm with the handles.
RAID 0, 1, 5, 6 and 10, plus JBOD. With four drives, RAID 5 protects against one drive failure and RAID 6 against two.
