Wi-Fi 7 with 4096-QAM modulation packs more data into each channel, giving compatible devices a speed boost. The 2.5 Gigabit WAN port accepts connections faster than 1 Gbit/s, and the second 2.5G port lets you wire a PC or NAS at the same speed. A USB 3.0 port shares an external drive across the network.
Homes replacing an older Wi-Fi 5 or Wi-Fi 6 router on a fast internet plan. Wi-Fi 7 also works with older devices. EasyMesh lets you add other EasyMesh routers or extenders, and the VPN server gives access to the home network from outside.
| Brand | TP-LINK |
|---|---|
| Product type | Tabletop router |
| Model name | Archer BE230 |
| Product colour | Black |
| Firewall | Yes |
| Modulation | 4096-QAM/OFDMA |
| DHCP server | Yes |
| Guest access | Yes |
| Media server | Yes |
| Parental control | Yes |
| Dynamic DNS (DDNS) | Yes |
| Built-in FTP server | Yes |
| WAN connection type | RJ-45 |
| Firmware upgradeable | Yes |
| Web-based management | Yes |
| Number of data streams | 4x4 |
| Works with Amazon Alexa | Yes |
| Access Control List (ACL) | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Operating relative humidity (H-H) | 10 - 90 |
| EAN | 4895252503685 |
| Support Samba (storage) | Yes |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
|---|---|
| USB port | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 5 |
| Ethernet LAN data rates | 1000/2500 |
| Ethernet LAN interface type | 2.5 Gigabit Ethernet |
| Ethernet WAN | Yes |
| SIM card slot | No |
| Port forwarding | Yes |
| Port triggering | Yes |
| 3G/4G USB modem compatibility | No |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
|---|---|
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (max) | 2882 Mbit/s |
| Antenna design | External |
| Security algorithms | WPA/WPA2/WPA2-Enterprise/WPA3/WPA-Enterprise |
| Antennas quantity | 4 |
| MU-MIMO technology | Yes |
| Number of guest networks (5 GHz) | 1 |
| Number of guest networks (2.4 GHz) | 1 |
| WLAN data transfer rate (first band) | 2882 |
| WLAN data transfer rate (second band) | 688 |
| On/off switch | Yes |
|---|---|
| Reset button | Yes |
| WPS push button | Yes |
| Output voltage | 12 V |
|---|---|
| Power source type | AC |
| Output current | 1.5 |
| Operating temperature (T-T) | 0 – 40 °C |
|---|---|
| IP address filtering | Yes |
| DMZ support | Yes |
|---|---|
| VPN support | OpenVPN Server PPTP VPN Server L2TP VPN Server WireGuard VPN Server |
| DDoS protection | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Works with the Google Assistant | Yes |
| Quality of Service (QoS) support | Yes |
No, Archer BE230 works on the 2.4 and 5 GHz bands.
Yes, through EasyMesh, with another EasyMesh router or range extender.
No. There is no SIM slot and 3G/4G USB modems are not supported.
