The rear panel carries HDMI, DVI-D and D-Sub, so both a new and an older monitor can be connected. HDMI supports 4K at 60 Hz. The outputs only work with a processor that has integrated graphics, because the picture comes from the CPU. The M.2 slot accepts both PCIe Gen3 x4 and SATA SSDs, and the board supports up to five drives in total. 50A power chokes and Full Spike Protection guard the components against voltage spikes.
Anyone building an office or home PC around an AM4 processor and DDR4 memory; users upgrading an older system who want to keep a DVI or D-Sub monitor; and anyone for whom wired networking and two memory slots in a compact micro-ATX case are enough.
| Brand | ASROCK |
|---|---|
| BIOS type | UEFI AMI |
| Component for | PC |
| Unbuffered memory | Yes |
| ECC сompatibility | Non-ECC |
| Number of memory slots | 2 |
| Motherboard form factor | micro ATX |
| PCI Express x1 (Gen 3.x) slots | 1 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| EAN | 4710483932267 |
| Processor manufacturer | AMD |
|---|---|
| Processor socket | Socket AM4 |
| CPU fan connector | Yes |
| Motherboard chipset family | AMD |
| Compatible processor series | AMD Ryzen 3000 Series |
| Maximum internal memory | 64 GB |
|---|---|
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Number of HDDs supported | 5 |
|---|---|
| Supported storage drive interfaces | M.2, SATA III |
| Graphics card | Radeon Vega |
|---|---|
| Graphics card family | AMD |
| Microphone in | Yes |
|---|---|
| Audio output channels | 7.1 |
| Front panel audio connector | Yes |
| HDMI ports quantity | 1 |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| LAN controller | Realtek RTL8111H |
| Wake-on-LAN ready | Yes |
| USB 2.0 connectors | 2 |
| PS/2 ports quantity | 1 |
| Ethernet interface type | Gigabit Ethernet |
| Number of COM connectors | 1 |
| VGA (D-Sub) ports quantity | 1 |
| ATX Power connector (24-pin) | Yes |
| Number of chassis fan connectors | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| Wi-Fi | No |
|---|
| Supported memory clock speeds | 2133/2400/2666/2933/3200/3466/3600/3733/3800/3866/4000/4133/4200/4266/4333/4400/4466/4500/4533 |
|---|
| Supported memory types | DDR4-SDRAM |
|---|
| Width | 230 mm |
|---|---|
| Depth | 201 mm |
The board has an AM4 socket, and the manufacturer data lists AMD Ryzen 3000 Series as the compatible series. Support for a specific model and the required BIOS version are in the ASRock CPU support list.
No. HDMI, DVI-D and D-Sub only output a picture with a processor that has integrated graphics. With a CPU without graphics, a separate graphics card in the PCIe 3.0 x16 slot is needed.
No, there is no Wi-Fi module on the board. Networking runs through the Gigabit Ethernet port, which also supports Wake-on-LAN.
