The dual-band (2.4 and 5 GHz) Wi-Fi 5 module and antenna are included, so there is no need to run a cable to the router, and Bluetooth connects wireless headphones, a gamepad or a keyboard. When a cable is handy, gigabit Ethernet is still there. The Hyper M.2 slot runs at PCIe Gen4 x4 and the SSD locks in with a tool-free latch. The fan headers detect on their own whether a fan runs in PWM or DC mode.
Home users and gamers whose PC sits far from the router; anyone who wants Bluetooth accessories without a separate adapter; and builders of a compact AM5 PC who keep the PCIe slot free for a graphics card.
| Brand | ASROCK |
|---|---|
| BIOS type | UEFI AMI |
| Component for | PC |
| BIOS memory size | 256 |
| ECC сompatibility | Non-ECC |
| RGB LED pin header | Yes |
| Number of memory slots | 2 |
| Motherboard form factor | micro ATX |
| Number of M.2 (M) slots | 1 |
| PCI Express x1 (Gen 3.x) slots | 2 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| EAN | 4711581496019 |
| Processor manufacturer | AMD |
|---|---|
| Motherboard chipset | AMD A620A |
| Processor socket | Socket AM5 |
| CPU fan connector | Yes |
| Motherboard chipset family | AMD |
| Compatible processor series | AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series |
| Number of CPU fan connectors | 1 |
| Maximum internal memory | 128 GB |
|---|---|
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Supported storage drive interfaces | SATA III, M.2 |
|---|
| Audio chip | Realtek ALC897 |
|---|---|
| Audio output channels | 7.1 |
| Front panel audio connector | Yes |
| HDMI ports quantity | 1 |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| LAN controller | Realtek RTL8111H |
| USB 2.0 connectors | 2 |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| Ethernet interface type | Gigabit Ethernet |
| EPS power connector (8-pin) | Yes |
| ATX Power connector (24-pin) | Yes |
| Number of SATA III connectors | 2 |
| Number of chassis fan connectors | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
| Number of EPS power connectors (8-pin) | 1 |
| Wi-Fi | Yes |
|---|---|
| Wi-Fi standards | 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Antenna included | Yes |
| Windows operating systems supported | Windows 10 x64/Windows 11 x64 |
|---|
| Cables included | SATA |
|---|---|
| Supported memory types | DDR5-SDRAM |
| Width | 244 mm |
|---|---|
| Depth | 229 mm |
| Product Net Weight | 1 kg |
Socket, memory, M.2, SATA and ports are the same on both, but the A620AM-P WIFI has a Wi-Fi 5 and Bluetooth 5.0 module with the antenna included. The A620AM-P only has an empty M.2 Key E slot for Wi-Fi.
The board has an AM5 socket and supports AMD Ryzen 7000, 8000 and 9000 Series processors. Support for a specific model is listed in the ASRock CPU support list.
The board has HDMI and DisplayPort 1.4 outputs. They show a picture when the processor has integrated graphics; otherwise the monitor connects to a graphics card.
