This is the black, Wi-Fi-free version of the AORUS ELITE AX ICE: the same 12+2+2 phase digital VRM, four DDR5 slots and a PCIe 5.0 x4 M.2 slot for next-generation SSDs. M.2 Thermal Guard cools the drives, and EZ-Latch quick release makes fitting the graphics card and SSDs simpler. If the PC is wired to the network anyway, there is no wireless module sitting unused.
Gamers and workstation builders whose PC runs on a network cable and who prefer a dark look. The 2.5 GbE port, two M.2 slots and four SATA ports cover fast networking and plenty of storage, while four case fan headers and two pump headers also suit liquid cooling.
| Brand | GIGABYTE |
|---|---|
| Product colour | Black |
| HDCP | Yes |
| Line-in | Yes |
| BIOS type | UEFI AMI |
| ACPI version | 5.0 |
| Component for | PC |
| DirectX version | 12.0 |
| BIOS memory size | 256 |
| Clear CMOS jumper | Yes |
| Headphone outputs | 1 |
| Unbuffered memory | Yes |
| ECC сompatibility | Non-ECC |
| RGB LED pin header | Yes |
| PC health monitoring | Fan/Temperature/Voltage/Water cooling |
| Number of memory slots | 4 |
| Motherboard form factor | ATX |
| Number of M.2 (M) slots | 2 |
| 1st M.2 largest key size | 25110 |
| 2nd M.2 largest key size | 22110 |
| Number of RGB LED pin headers | 5 |
| PCI Express x16 (Gen 4.x) slots | 2 |
| Products per shipping (inner) case | 1 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| System Management BIOS (SMBIOS) version | 2.7 |
| Desktop Management Interface (DMI) version | 2.7 |
| Warranty | 3 years |
| EAN | 4719331849818 |
| Maximum resolution | 4096 x 2160 |
|---|
| Processor manufacturer | AMD |
|---|---|
| Motherboard chipset | AMD B650 |
| Processor socket | Socket AM5 |
| CPU fan connector | Yes |
| Motherboard chipset family | AMD |
| Compatible processor series | AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series |
| Supported processor sockets | Socket AM5 |
| Number of CPU fan connectors | 2 |
| Maximum internal memory | 256 GB |
|---|---|
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Maximum internal memory per slot | 64 |
| Number of HDDs supported | 4 |
|---|---|
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 6 |
| Supported storage drive interfaces | M.2, SATA III |
| Audio chip | Realtek ALC897 |
|---|---|
| Audio output channels | 7.1 |
| Front panel audio connector | Yes |
| HDMI ports quantity | 1 |
|---|---|
| HDMI version | 2.1 |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| TPM connector | Yes |
| LAN controller | Realtek RTL8125 |
| S/PDIF out port | Yes |
| USB 2.0 connectors | 2 |
| 12V power connector | Yes |
| DisplayPort version | 1.4 |
| Serial port headers | 1 |
| Thunderbolt headers | 1 |
| DisplayPorts quantity | 1 |
| Front panel connector | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| USB 3.2 Gen 2x2 connectors | 1 |
| EPS power connector (8-pin) | Yes |
| ATX Power connector (24-pin) | Yes |
| Number of SATA III connectors | 4 |
| Number of water pump connectors | 2 |
| Number of chassis fan connectors | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Number of EPS power connectors (8-pin) | 1 |
| Wi-Fi | No |
|---|
| Bundled software | Norton® Internet Security (OEM version) LAN bandwidth management software |
|---|---|
| Windows operating systems supported | Windows 10 x64/Windows 11 x64 |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
|---|---|
| Battery type | CR2032 |
| Number of battery cells | 1 |
| Power source type | ATX |
| Battery weight | 3 |
| Lithium weight per battery | 0.07 |
| RAID levels | 0/1/10 |
|---|---|
| Cooling type | Passive |
| Supported memory clock speeds | 4400/4800/5200/5600/6000/6200/6400/6600/6666/6800/7000/7200/7600/7800/8000 |
| Supported memory clock speed (max) | 8000 |
| RAID support | Yes |
|---|---|
| Screws included | Yes |
| Batteries included | Yes |
| Supported memory types | DDR5-SDRAM |
| Parallel processing technology support | Not supported |
| Width | 244 mm |
|---|---|
| Depth | 244 mm |
| Height | 35 mm |
| Weight | 1.66 kg |
According to the manufacturer, AMD Ryzen 7000, 8000 and 9000 series processors for the AM5 socket.
No, there is no Wi-Fi or Bluetooth on the board. Networking runs through the 2.5 GbE port; wireless needs a separate adapter.
Yes, the first M.2 slot runs at PCIe 5.0 x4 and takes drives up to 25110 length. The second M.2 slot is PCIe 4.0 x4.
