Sixteen ports connect computers, printers, IP phones and other devices for which 100 Mbit/s is enough. Each port detects the cable type and the connected device's speed on its own. Flow control keeps transfers stable even when several devices send data at once, and power consumption stays minimal.
Home offices and small workgroups with lots of simple network devices; extending an existing 100 Mbit/s network; and anyone who needs a quiet switch that can hang on a wall. For moving large files, a gigabit model is the more sensible choice.
| Brand | TP-LINK |
|---|---|
| Model name | 16-Port 10/100Mbps Desktop Switch |
| Product colour | Black |
| Fanless | Yes |
| Stackable | No |
| User guide | Yes |
| Full duplex | Yes |
| Half duplex | Yes |
| Rack mounting | Yes |
| Wall mountable | Yes |
| Auto-negotiation | Yes |
| MAC address table | 2000 |
| Store-and-forward | Yes |
| Sustainability compliance | Yes |
| Minimum system requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7, MAC OS, NetWare, UNIX, Linux |
| Operating relative humidity (H-H) | 10 - 90 |
| EAN | 6935364020293 |
| Switching capacity | 3.2 |
|---|---|
| Storage temperature (T-T) | -40 - 70 |
| Storage relative humidity (H-H) | 5 - 90 |
| Ethernet LAN data rates | 10,100 |
|---|---|
| Power over Ethernet (PoE) | No |
| Power connector | DC-in jack |
| Copper ethernet cabling technology | 100BASE-TX/10BASE-T |
| Fast Ethernet (copper) ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Networking standards | IEEE 802.3u/IEEE 802.3x |
|---|
| Switch type | Unmanaged |
|---|
| AC adapter included | Yes |
|---|---|
| Power consumption (max) | 3.23 W |
| Power source | DC |
| Input current | 0.6 |
| DC input voltage | 9 |
| Power supply included | Yes |
| Operating temperature (T-T) | 0 – 40 °C |
|---|---|
| Heat dissipation | 11.01 |
| LED indicators | Yes |
|---|---|
| 10G support | No |
| Package type | Box |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
| MAC address auto-learning supported | Yes |
| Width | 200 mm |
|---|---|
| Depth | 142 mm |
| Height | 40 mm |
No. All 16 ports are Fast Ethernet, up to 100 Mbit/s. A gigabit computer connected to it will run at 100 Mbit/s.
Yes, according to the manufacturer it can sit on a desk or be fixed to a wall.
Yes. The switch runs on 9 V DC and the matching power adapter is included.
