The web interface lets you switch PoE on or off for each port, so a frozen camera can be rebooted remotely. VLANs keep cameras, controllers and the office network apart, QoS gives priority to the traffic that matters, and port mirroring helps with troubleshooting. The two SFP slots connect the switch to fibre.
System integrators who need a PoE switch with VLAN segmentation on an industrial site; surveillance installers who want to reboot cameras remotely; and sites where equipment has to run from −40 to 75 °C.
| Brand | TELTONIKA |
|---|---|
| Model name | TSW202000000 |
| Product colour | Aluminium/Blue |
| Housing material | Aluminium |
| Stackable | No |
| Full duplex | Yes |
| Jumbo frames | 10000 |
| IGMP snooping | Yes |
| Rack mounting | No |
| Auto-negotiation | Yes |
| Link aggregation | Yes |
| DIN rail mounting | Yes |
| MAC address table | 8000 |
| Web-based management | Yes |
| Active link detection | Yes |
| Installed SFP modules quantity | 2 |
| EAN | 4779051840281 |
| Switching capacity | 20 |
|---|
| Power over Ethernet (PoE) | Yes |
|---|---|
| Port mirroring | Yes |
| Power connector | Terminal block (3-pin) |
| Total Power over Ethernet (PoE) budget | 240 |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Power over Ethernet (PoE) ports quantity | 8 |
| Power over Ethernet (PoE) power per port | 30 |
| Power over Ethernet (PoE) type supported | Active PoE |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Networking standards | IEEE 802.1p/IEEE 802.3af/IEEE 802.3at/IEEE 802.3z |
|---|
| Switch type | Managed |
|---|---|
| Reset button | Yes |
| Switch layer | L2 |
| Power supply included | No |
|---|
| Operating temperature (T-T) | 0 – 40 – 75 °C |
|---|
| International Protection (IP) code | IP30 |
|---|---|
| LED indicators | Power/Status |
| 10G support | No |
| VLAN support | Yes |
| DHCP features | DHCP client |
| Jumbo frames support | Yes |
| Quality of Service (QoS) support | Yes |
| Width | 132 mm |
|---|---|
| Depth | 44.2 mm |
| Height | 122 mm |
| Weight | 610 g |
Yes. It is a managed L2 switch configured through a web interface, with support for VLANs, QoS, IGMP snooping, port mirroring and link aggregation.
Eight at once: each port delivers up to 30 W and the 240 W budget covers every port at full load. The devices need to support IEEE 802.3af or 802.3at.
Power goes in through a 3-pin terminal block and the power supply is chosen separately. The manufacturer does not specify the input voltage range.
