When the total draw of PoE devices reaches 65 W, the switch cuts power to the lowest-priority port, in the order port 1, 2, 3, 4. So the most important device, such as a security camera, belongs in port 1. Port mirroring, loop prevention and cable diagnostics help you track down a network fault quickly, and the fanless housing runs silently.
Homes and small offices that need to power up to four PoE devices without separate adapters; users moving on from an unmanaged switch who want to try VLANs and traffic prioritisation; and small surveillance setups where the cameras sit far from a power socket.
| Brand | TP-LINK |
|---|---|
| Model name | 5-Port Gigabit Easy Smart PoE Switch with 4-Port PoE+ |
| Product colour | Black |
| Fanless | Yes |
| User guide | Yes |
| Jumbo frames | 16000 |
| IGMP snooping | Yes |
| Rack mounting | No |
| Rate limiting | Yes |
| Forwarding rate | 7.44 |
| Number of VLANs | 4000 |
| Auto-negotiation | Yes |
| Link aggregation | Yes |
| Number of queues | 4 |
| MAC address table | 2000 |
| Store-and-forward | Yes |
| Packet buffer memory | 1 |
| Web-based management | Yes |
| Broadcast storm control | Yes |
| Operating relative humidity (H-H) | 10 - 90 |
| EAN | 6935364052744 |
| Switching capacity | 10 |
|---|---|
| Storage temperature (T-T) | -40 - 70 |
| Storage relative humidity (H-H) | 5 - 95 |
| Power over Ethernet (PoE) | Yes |
|---|---|
| Port mirroring | Yes |
| Virtual LAN features | Port-based VLAN/Tagged VLAN |
| Copper ethernet cabling technology | 1000BASE-T/100BASE-FX/100BASE-TX/10BASE-T |
| Total Power over Ethernet (PoE) budget | 65 |
| Gigabit Ethernet (copper) ports quantity | 5 |
| Power over Ethernet (PoE) power per port | 30 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Networking standards | IEEE 802.1p/IEEE 802.1Q/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x |
|---|
| Switch type | Managed |
|---|---|
| Switch layer | L2 |
| Power consumption (max) | 75.16 W |
|---|---|
| Input voltage | 53.5 V |
| Power source | DC |
| Input current | 1.31 |
| Power supply included | Yes |
| Operating temperature (T-T) | 0 – 40 °C |
|---|---|
| Heat dissipation | 256.3 |
| LED indicators | Activity/Link/PoE/Power/Speed/Status |
|---|---|
| 10G support | No |
| VLAN support | Yes |
| Auto MDI/MDI-X | Yes |
| Loop protection | Yes |
| Flow control support | Yes |
| Jumbo frames support | Yes |
| Cable types supported | Cat3/Cat4/Cat5/Cat5e/Cat6 |
| Quality of Service (QoS) support | Yes |
| Width | 99.8 mm |
|---|---|
| Depth | 98 mm |
| Height | 25 mm |
Four: ports 1–4 are PoE+ ports, and the fifth is a regular gigabit port, for example for the router. Each port gets up to 30 W, with 65 W across all of them.
Not necessarily, it works as soon as the cables are plugged in. VLANs, QoS, IGMP snooping and port mirroring can be set up when needed through the web interface or the TP-Link utility.
No, the housing has no fan, so the unit runs completely silently and can sit in a living room or study.
