Lian Li EDGE Gold 1000 power supply 1000 W, 80 PLUS Gold, RS Hub, white
LIAN LI

Lian Li EDGE Gold 1000 power supply 1000 W, 80 PLUS Gold, RS Hub, white

The Lian Li EDGE Gold 1000 is a white, fully modular 1000 W power supply with a built-in RS Hub. The hub provides extra connections straight from the PSU, freeing up motherboard USB headers, while ATX 3.1 support and a 12V-2×6 cable cover current graphics cards.

  • Wattage: 1000 W, up to 83.3 A on the +12V rail
  • Efficiency: 80 PLUS Gold, Cybenetics Platinum-level per the manufacturer
  • Cabling: fully modular, two-colour 12V-2×6 cable
  • Connectors: 2 × PCIe 6+2, 4 × Molex, dual-sided 20+4 ATX output
  • RS Hub: integrated hub, USB-A and USB-to-USB cables included
  • Size and cooling: 150 × 86 × 150 mm, 135 mm FDB fan

Description

RS Hub cuts down the cable clutter

The integrated RS Hub supplies extra connections directly from the power supply, so not everything has to run to the motherboard USB headers and cable runs inside the case stay shorter. Two cables come in the box for the hub, USB-A and USB-to-USB, so you can pick the routing that suits your build. The AC inlet rotates 90° and the unit can also be mounted on its side.

Who this power supply is for

Builders of a white, carefully cabled gaming PC who are short of USB headers on the motherboard or want fewer wires behind the tray. 1000 W leaves headroom for a top graphics card and a powerful processor, and owners of dual-chamber cases can use side mounting.

Specifications

General

BrandLIAN LI
Model nameRS1000G
Product colourWhite
PurposePC
ATX version3.1
Cabling typeFully-Modular
Fan diameter135
Number of fans1
Mean time between failures (MTBF)100000
EAN4718466018960

Processor

CPU power cable length700

Ports

Motherboard power connector20+4 pin ATX
ATX power connector (20+4 pin)Yes
PCI Express power connectors (6+2 pin)2
Peripheral (Molex) power connectors (4-pin)4

Battery & power

AC input voltage100 – 240 V
AC input frequency50/60
Total power1000
Input current8 - 15
Combined power (+5V)100
80 PLUS certification80 PLUS Gold
Combined power (+12V)1000
Combined power (+3.3V)100
Combined power (+5Vsb)15
Max output current (+5V)20
Max output current (+12V)83.3
Power protection featuresNo load operation/Over current/Over power/Over voltage/Short circuit/Surge & inrush protection (SIP)/Under temperature/Under voltage
Motherboard power cable length620
PCI Express power cable length650
Power Factor Correction (PFC) typeActive
Power supply unit (PSU) form factorATX
Peripheral (Molex) power cable length500

Performance & capacities

Noise level36.21 dB
Operating temperature (T-T)0 – 40 °C
Fan speed0 - 1600

Features

Bearing technologyFDB

Dimensions & weight

Width86 mm
Depth150 mm
Height150 mm

Questions & answers

What is the RS Hub and how is it connected?

The RS Hub is a hub built into the power supply that provides extra connections straight from the unit. It connects to the motherboard with the included USB-A or USB-to-USB cable.

Can the unit be mounted on its side?

Yes. The AC inlet rotates 90° and the motherboard cable can attach on either side, so the unit works in a standard position or vertically on the side of a dual-chamber case.

Which protections does it have?

Protection covers over current, over power, over voltage, under voltage, short circuit and surge and inrush (SIP). The operating range is 0–40 °C.
