Unitree A2 industrial quadruped robot dog, LiDAR + HD camera, 25 kg payload
UNITREE

Unitree A2 industrial quadruped robot dog, LiDAR + HD camera, 25 kg payload

The Unitree A2 is an industrial-grade quadruped robot dog designed to work wherever standard solutions fail. Weighing about 37 kg, it moves at up to 5 m/s, carries up to 25 kg while walking and holds up to 100 kg in static mode. It climbs steps of up to 30 cm and slopes of up to 45°, moving across stairs, rubble and rocks. Twelve PMSM motors with around 180 N·m of torque provide precise, long-lasting operation.

Description

Perception comes from an industrial LiDAR and a front HD camera, with front lighting for low visibility; a rear LiDAR and GPS/4G are optional. Two hot-swappable 9000 mAh batteries deliver up to 5 h and about 20 km unloaded, or about 3 h with a 25 kg load. On board are an 8-core processor and an Intel Core i7, with 2 × RS485, 2 × CAN, 2 × Ethernet, 4 × USB-C, Wi-Fi 6, Bluetooth 5.2, OTA and SDK/API. IP56, –20 °C to 55 °C.

  • Type: industrial quadruped robot dog (standard version), 12 DoF
  • Payload: up to 25 kg walking, up to 100 kg static
  • Speed and terrain: up to 5 m/s, steps up to 30 cm, slopes ~45°
  • Batteries and runtime: 2 × 9000 mAh, hot-swap; ~5 h / 20 km unloaded
  • Perception: LiDAR + HD camera + front lighting; optional rear LiDAR, GPS/4G
  • Computing and interfaces: 8-core CPU + Intel Core i7; 2 × RS485, 2 × CAN, 2 × Ethernet, 4 × USB-C
  • Weight and size: ~37 kg, 82 × 44 × 57 cm standing, 72 × 55 × 22 cm folded, IP56
  • MPN: 080986, manufacturer Unitree
  • Warranty: 12 months

Specifications

BrandUNITREE
Weight (boxed)83 kg
Warranty12 months
EAN5907085529752
