ARCTIC Freezer 36 A-RGB ACFRE00124A CPU cooler 2 × 120 mm, black

The ARCTIC Freezer 36 A-RGB (ACFRE00124A) is a black tower CPU cooler with two 120 mm PWM fans and A-RGB lighting from 12 LEDs. The fans run on fluid dynamic bearings at up to 2000 rpm, the cooler is 159 mm tall and it mounts on LGA 1700, LGA 1851, AM4 and AM5.

  • Type and size: tower cooler, 126 × 104 × 159 mm (W × D × H), 917 g
  • Sockets: Intel LGA 1700, LGA 1851; AMD AM4, AM5
  • Fans: 2 × 120 mm, FDB bearing, PWM, 200–2000 rpm, 12 V
  • Lighting: A-RGB, 12 LEDs, 3-pin connector
  • Heatsink: 4 heat pipes, aluminium fins
  • Colour: black

Description

A-RGB lighting with 12 LEDs

Unlike the silver Freezer 36, this version has addressable RGB lighting: the 12 LEDs plug into the motherboard’s A-RGB header through a 3-pin connector, and colours and effects are set in the board’s software. The cooler is all black, so the light stands out well behind a glass panel.

Faster fans up to 2000 rpm

Two 120 mm fans run on fluid dynamic bearings, each with its own 4-pin PWM connector. The speed range is 200–2000 rpm, so the top end is 200 rpm higher than on the unlit model. Four heat pipes move heat to the aluminium fins; the fan cable is 0.28 m long.

Who this CPU cooler is for

The Freezer 36 A-RGB is for a glass-panel build on LGA 1700, LGA 1851, AM4 or AM5 where the cooler’s lighting should match the other A-RGB parts. The case must take a 159 mm tall cooler.

Specifications

General

BrandARCTIC
Model nameFreezer 36 A-RGB (Black)
Product colourBlack
TypeAir cooler
Bearing typeFluid Dynamic Bearing (FDB)
Fan diameter120
Fins materialAluminium
Number of LEDs12
Illumination LEDYes
Suitable locationProcessor
Illumination colourMulti
Sustainability complianceYes
EAN4895213704151

Processor

Supported processor socketsLGA 1700/LGA 1851/Socket AM4/Socket AM5

Ports

Fan connector4-pin + 4-pin
LED connector type3-pin

Battery & power

Cable length0.28 m
Rated current0.11
Rated voltage12

Performance & capacities

Operating temperature (T-T)0 – 40 °C
Number of heat pipes4
Rotational speed (max)2000
Rotational speed (min)200

Features

Package typeBox
Pulse-width modulation (PWM) supportYes

Dimensions & weight

Width126 mm
Depth104 mm
Height159 mm
Weight917 g

Questions & answers

How is the lighting connected?

The lighting has a 3-pin LED connector that goes to the addressable RGB header on the motherboard. The fans connect separately through 4-pin PWM connectors.

Which sockets does the cooler support?

ARCTIC lists LGA 1700, LGA 1851, AM4 and AM5.

Is thermal paste included?

The manufacturer does not specify. If there is no paste in the box, apply a thin layer to the CPU before mounting.
