The first M.2 slot supports PCIe 5.0 at up to 128 Gbit/s and sits under an M.2 heatsink held by captive screws. The graphics card goes into a PCIe 5.0 x16 slot. A Thunderbolt (USB4) header lets a separate ASUS add-on card provide connections of up to 40 Gbit/s. A pre-mounted I/O shield, BIOS FlashBack, Q-Antenna and Q-LED Core make assembly easier.
Builders of a new AM5 gaming PC or powerful workstation who do not want the board to limit later upgrades: PCIe 5.0 for graphics and SSD, three M.2 slots and up to 256 GB of memory. A dedicated pump header serves liquid cooling, and four headers take case fans.
| Brand | ASUS |
|---|---|
| Product colour | Black |
| Line-in | Yes |
| BIOS type | UEFI AMI |
| Component for | PC |
| BIOS memory size | 256 |
| Headphone outputs | 1 |
| Unbuffered memory | Yes |
| ECC сompatibility | Non-ECC |
| RGB LED pin header | Yes |
| Number of memory slots | 4 |
| Motherboard form factor | ATX |
| Number of M.2 (M) slots | 3 |
| 1st M.2 largest key size | 2280 |
| 2nd M.2 largest key size | 2280 |
| 3rd M.2 largest key size | 22110 |
| Number of RGB LED pin headers | 3 |
| PCI Express x16 (Gen 3.x) slots | 2 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| 3rd M.2 highest PCI Express generation | 4.0 |
| EAN | 4711387932445 |
| Processor manufacturer | AMD |
|---|---|
| Motherboard chipset | AMD B650 |
| Processor socket | Socket AM5 |
| CPU fan connector | Yes |
| Motherboard chipset family | AMD |
| Compatible processor series | AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series |
| Supported processor sockets | Socket AM5 |
| Number of CPU fan connectors | 2 |
| Maximum internal memory | 256 GB |
|---|---|
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Number of HDDs supported | 4 |
|---|---|
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 7 |
| Supported storage drive interfaces | M.2, PCI Express 5.0, SATA III |
| On-board graphics card | No |
|---|
| Microphone in | Yes |
|---|---|
| Audio output channels | 7.1 |
| Front panel audio connector | Yes |
| HDMI ports quantity | 1 |
|---|---|
| HDMI version | 2.1 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| TPM connector | Yes |
| USB 2.0 connectors | 3 |
| DisplayPort version | 1.4 |
| Thunderbolt headers | 1 |
| S/PDIF out connector | Yes |
| WiFi-AP antenna jack | 2 |
| DisplayPorts quantity | 1 |
| Front panel connector | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Number of COM connectors | 1 |
| Chassis intrusion connector | Yes |
| EPS power connector (8-pin) | Yes |
| ATX Power connector (24-pin) | Yes |
| Number of SATA III connectors | 4 |
| Number of water pump connectors | 1 |
| Number of chassis fan connectors | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Number of EPS power connectors (8-pin) | 1 |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| Wi-Fi | Yes |
|---|---|
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Antenna included | Yes |
| Windows operating systems supported | Windows 10 x64/Windows 11 |
|---|
| Power source type | ATX |
|---|
| RAID levels | 0/1/10/5 |
|---|---|
| Cooling type | Passive |
| Supported memory clock speed (max) | 8000 |
| Cables included | SATA |
|---|---|
| RAID support | Yes |
| Screws included | Yes |
| Supported memory types | DDR5-SDRAM |
| Parallel processing technology support | Not supported |
| Width | 305 mm |
|---|---|
| Depth | 244 mm |
| Height | 48 mm |
| Weight | 1.05 kg |
The board has an AMD AM5 socket, and the manufacturer lists Ryzen 7000, 8000 and 9000 Series processors as compatible.
Three: the first slot is PCIe 5.0 (up to 2280), the second PCIe 4.0 (up to 2280) and the third PCIe 4.0 (up to 22110). There are also four SATA III ports.
The box includes a Wi-Fi antenna, SATA cables and screws.
