ASUS

ASUS Prime B550M-A WiFi III AMD Micro ATX Motherboard

  • Processor manufacturerAMD
  • Maximum internal memory128 GB
  • Supported storage drive typesHDD & SSD
  • RAID levels0/1/10
  • Top Wi-Fi standardWi-Fi 6 (802.11ax)
  • Audio output channels7.1

The ASUS Prime B550M-A WiFi III is a compact micro ATX motherboard built on the AMD B550 chipset for Socket AM4 processors. This board packs essential features into a small footprint, making it ideal for budget-conscious builders and those working with space constraints.

Description

Solid Performance in a Compact Design

  • 4 DDR4 memory slots support up to 128GB RAM for multitasking and content creation
  • Dual M.2 slots enable fast NVMe SSD storage configuration
  • Built-in WiFi connectivity keeps your system wireless-ready without additional cards
  • 6 USB 3.2 ports plus legacy PS/2 support cover your peripheral needs
  • PCIe 4.0 x16 slot accommodates modern graphics cards with full bandwidth

This motherboard suits PC builders upgrading from older AM4 systems, home office setups that need reliable connectivity, and small-form-factor builds where space matters. It's a practical choice for everyday computing, light gaming, and office work without compromise.

Specifications

General

BrandASUS
Product colourMulticolour
BIOS typeUEFI AMI
Component forPC
BIOS memory size256
Clear CMOS jumperYes
Headphone outputs1
Unbuffered memoryYes
ECC сompatibilityECC
RGB LED pin headerYes
Number of memory slots4
Motherboard form factormicro ATX
Number of M.2 (M) slots2
1st M.2 largest key size22110
2nd M.2 largest key size2280
PCI Express x1 (Gen 3.x) slots2
PCI Express x16 (Gen 4.x) slots1
1st M.2 highest PCI Express generation4.0
2nd M.2 highest PCI Express generation3.0
EAN4711081309741

Processor

Processor manufacturerAMD
Motherboard chipsetAMD B550
Processor socketSocket AM4
CPU fan connectorYes
Motherboard chipset familyAMD
Compatible processor seriesAMD Ryzen 3000 Series/AMD Ryzen 5000 Series
Supported processor socketsSocket AM4

Memory

Maximum internal memory128 GB
Memory channelsDual-channel
Memory slots typeDIMM

Storage

Drivers includedYes
Supported storage drive typesHDD & SSD
Number of storage drives supported6
Supported storage drive interfacesM.2, PCI Express 3.0, PCI Express 4.0, SATA III

Graphics

On-board graphics cardNo

Audio

Microphone inYes
Audio output channels7.1
Front panel audio connectorYes

Ports

HDMI ports quantity1
HDMI version2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
USB connector typeUSB Type-A
Ethernet LANYes
Ethernet LAN (RJ-45) ports1
TPM connectorYes
LAN controllerRealtek RTL8111H
Wake-on-LAN readyYes
USB 2.0 connectors2
12V power connectorYes
PS/2 ports quantity1
DVI-D ports quantity1
S/PDIF out connectorYes
WiFi-AP antenna jack1
Ethernet interface typeGigabit Ethernet
Number of COM connectors1
VGA (D-Sub) ports quantity1
EPS power connector (8-pin)Yes
ATX Power connector (24-pin)Yes
Number of SATA III connectors4
Number of EATX power connectors1
Number of chassis fan connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors1

Connectivity

Wi-FiYes
Wi-Fi standards802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)
Top Wi-Fi standardWi-Fi 6 (802.11ax)
BluetoothYes
Bluetooth version5.2

Software & security

Windows operating systems supportedWindows 10 x64/Windows 11 x64

Performance & capacities

RAID levels0/1/10
Supported memory clock speeds2133/2400/2666/2800/3000/3200/3333/3466/3600/3733/3866/4000/4133/4266/4400/4466/4600/4800/4866

Features

Cables includedSATA
RAID supportYes
Supported memory typesDDR4-SDRAM
Parallel processing technology supportNot supported

Dimensions & weight

Width244 mm
Depth244 mm
Height67 mm
Weight845 g
