Dahua PFS4218-16ET-240-V3 PoE network switch 16 ports, 2 × combo SFP, 802.3bt

The Dahua PFS4218-16ET-240-V3 is a PoE network switch with 16 RJ-45 ports and two combo SFP uplinks for surveillance and office networks. The red port supports IEEE 802.3bt and supplies up to 90 W, and the manufacturer describes a simple web interface.

  • Ports: 16 × RJ-45 + 2 × combo SFP uplink
  • PoE: IEEE 802.3af/at/bt, red port up to 90 W, intelligent PoE, watchdog
  • Features: web interface, IGMP snooping, link aggregation, port mirroring, DHCP client
  • Performance: 8.8 Gbps switching capacity, 5.36 Mpps, 4000-entry MAC table
  • Power and housing: 100–240 V, power supply included, desktop, 440 × 300 × 44 mm

Description

Web interface and long PoE runs

The web interface keeps setup simple: IGMP snooping keeps multicast streams from several cameras under control, port mirroring helps with traffic analysis and link aggregation combines connections. PoE links reach up to 250 metres, and the watchdog restarts a frozen camera by itself. The data applies to hardware versions V2.0 and V3.0.

Who this network switch is for

Surveillance systems where 16 cameras connect to one switch and a single high-draw device, such as a PTZ camera, needs up to 90 W, and installers who want a fibre uplink to the recorder.

Specifications

General

BrandDAHUA
StackableNo
Throughput5.36
IGMP snoopingYes
Rack mountingNo
Link aggregationYes
MAC address table4000
Transmission distance (max)0.25
EAN6923172528124

Storage

Switching capacity8.8

Ports

Power over Ethernet (PoE)Yes
Port mirroringYes
Combo SFP ports quantity2
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity16

Connectivity

Networking standardsIEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z

Keyboard & controls

Switch typeUnmanaged

Battery & power

Power consumption (typical)240 W
AC input voltage100 – 240 V
Power sourceAC
Power supply includedYes

Features

10G supportNo
Package typeBox
DHCP featuresDHCP client

Dimensions & weight

Width440 mm
Depth300 mm
Height44 mm

Questions & answers

What is the total PoE budget?

The supplier data contradicts itself on this, so we do not state a total budget. What is certain is that the red 802.3bt port supplies up to 90 W.

Does the switch have a web interface?

Yes, the manufacturer describes web management. The data lists IGMP snooping, link aggregation, port mirroring and a DHCP client.

Can it be rack-mounted?

No, the manufacturer data shows no rack mounting. The housing is a desktop unit measuring 440 × 300 × 44 mm.
