Lenovo ThinkSmart Core G2 + IP Controller conference system Teams, Core Ultra 5

The Lenovo ThinkSmart Core + IP Controller G2 is a second-generation conference system kit for Microsoft Teams Rooms (MTR): a room computer with an Intel Core Ultra 5 135H processor and a 10.1-inch touch control panel. The computer has 16 GB of DDR5 memory in replaceable SO-DIMM modules, a 256 GB SSD and Windows 11 IoT Enterprise.

  • Kit: ThinkSmart Core G2 room computer and Lenovo IP Controller, MTR version
  • Processor: Intel Core Ultra 5 135H, 14 cores, Intel Arc graphics
  • Memory and storage: 16 GB DDR5 5600 MHz (2 × 8 GB SO-DIMM) + 256 GB SSD
  • Controller: Lenovo IP Controller, 10.1″ multi-touch display
  • Wireless: Wi-Fi 6 (802.11ax), Bluetooth 5.3
  • System: Windows 11 IoT Enterprise, Microsoft Teams Rooms

Description

A second-generation Core for Teams rooms

G2 marks the second generation of the ThinkSmart Core. The kit contains the permanent meeting room computer that runs Teams Rooms and a touch panel on the table from which people join meetings. MTR in the name stands for the Microsoft Teams Rooms version. No camera, video bar or displays are included; those are chosen separately to suit the size of the room.

Core Ultra 5 and Arc graphics with headroom

The Intel Core Ultra 5 135H is a 14-core processor paired with integrated Intel Arc graphics. Compared with the first-generation Core, which uses a four-core Intel Core i5-1145G7E, that is several times as many cores. In a meeting room this means headroom for video processing, showing several displays and the camera feed at once, and for software updates that grow more demanding over the years.

Memory that is not soldered

The 16 GB of DDR5 memory at 5600 MHz comes as two 8 GB SO-DIMM modules. Two modules run in dual-channel mode, giving the processor and integrated graphics more memory bandwidth. Unlike the soldered DDR4 in the first-generation Core, the modules can be replaced if needed; the maximum supported capacity is listed in the Lenovo hardware maintenance manual.

Windows 11 IoT Enterprise for a single job

The computer ships with Windows 11 IoT Enterprise, the edition of Windows for dedicated devices that do one specific job, in this case a Teams Rooms meeting room. The system and app sit on a 256 GB SSD that boots quickly and has room for updates. As a result the room computer behaves like an appliance rather than an ordinary office PC that people might use for something else.

Touch panel and wireless connectivity

The Lenovo IP Controller has a 10.1-inch multi-touch display: starting a meeting, adding participants and muting are done with a finger, with no keyboard or mouse. The IP in its name points to a controller connected over the network. The computer supports Wi-Fi 6 (802.11ax) and Bluetooth 5.3, a newer version than the Bluetooth 5.0 of the first generation.

Who this conference system is for

Companies that use Microsoft Teams and are fitting out new meeting rooms or replacing a first-generation ThinkSmart Core; IT departments for whom Windows 11 IoT Enterprise and replaceable memory matter; and organisations that choose the camera or video bar separately and want a computer with performance headroom for the years ahead.

Specifications

General

BrandLenovo
Colour of productBlack
Controller typeLenovo IP Controller, 10.1" Touch Controller, Multi-touch
EAN198155758935

Display

TouchscreenYes

Processor

Processor familyIntel Core Ultra 5
Processor model135H
Processor cores14

Memory

Internal memory16 GB
Internal memory typeSO-DIMM DDR5
Memory layout (slots x size)2x8 GB
Memory clock speed5600 MHz

Storage

Total storage capacity256 GB
Storage mediaSSD

Graphics

On-board graphics adapter modelIntel Arc Graphics

Connectivity

Wi-FiYes
Wi-Fi standards802.11ax
BluetoothYes
Bluetooth version5.3

Software & security

Operating system installedWindows 11 IoT Enterprise

Dimensions & weight

Net weight1.98 kg

Questions & answers

How does it differ from the first-generation ThinkSmart Core?

The G2 uses an Intel Core Ultra 5 135H (14 cores) with Intel Arc graphics, while the first generation has a four-core Intel Core i5-1145G7E with Iris Xe graphics. Memory is DDR5 in SO-DIMM modules instead of soldered DDR4, and Bluetooth is version 5.3.

Can the memory be upgraded?

The memory is two 8 GB SO-DIMM modules rather than soldered, so the modules can be replaced. The maximum capacity is listed in the Lenovo hardware maintenance manual.

Is a camera included?

No. The kit consists of the ThinkSmart Core G2 computer and the IP Controller touch panel; a camera or video bar is chosen separately.

Which ports does the computer have?

The manufacturer does not specify the port list for this version. The exact list is in the Lenovo ThinkSmart Core G2 datasheet.
