Lindy 42817 active USB 2.0 extension cable 5 m, A–A, Slim
LINDY

Lindy 42817 active USB 2.0 extension cable 5 m, A–A, Slim

The Lindy 42817 is a 5 m active USB 2.0 extension cable from the Active Extension Slim series. The repeater electronics fit inside a standard-size USB connector, so there is no bulky box on the cable, and the link can be extended up to 25 metres.

  • Connectors: USB-A male to the computer, USB-A female to the device
  • Length: 5 m, active electronics in the connector
  • Data transfer: USB 2.0, up to 480 Mbit/s
  • Daisy-chaining: up to 5 cables in series, 25 m in total
  • Build: gold-plated contacts, shielded connectors, PVC jacket, 4.8 mm diameter

Description

A slim connector with the repeater inside

Many active USB cables carry the repeater in a large plastic housing that does not fit into tight spaces. On the 42817 the active electronics are built into a regular USB-A connector. The cable is Plug and Play, needs no drivers and works with any computer that has a USB-A port. Speed over the full length is USB 2.0, up to 480 Mbit/s, and operating temperature is 0–70 °C.

Who this USB cable is for

Anyone whose printer, webcam, keyboard or other USB-A device sits further from the computer than a normal cable reaches. Up to five cables can be chained, so instead of 5 m the line can reach 25 metres when needed.

Specifications

General

BrandLINDY
Model name5m USB 2.0 Active Extension Slim
Product colourBlack
Cable typeRound cable
AWG wire size24/28
Plug and PlayYes
Cable diameter4.8
Contact materialBrass
Bend radius (min)48
Conductor materialTinned copper
Nominal attenuation24AWG: 93.25Ohm/km 28AWG: 237.25Ohm/km
Transmission mediumTwisted pair
Maximum data transfer rate480
EAN4002888428170

Storage

Storage temperature (T-T)-10 - 80

Ports

USB versionUSB 2.0
Connector 1USB A
Connector 2USB A
Connector 1 genderMale
Connector 2 genderFemale
Connector materialNickel
Connector shieldingYes
Cable jacket materialPolyvinyl chloride (PVC)
Connector 1 form factorStraight
Connector 2 form factorStraight
Connector shield materialAluminium
Connector contacts platingGold
Connector housing materialPlastic
Connector 1 dimensions (WxDxH)15 x 40 x 6
Connector 2 dimensions (WxDxH)15 x 45 x 8

Battery & power

Cable length5 m

Performance & capacities

Operating temperature (T-T)0 – 70 °C

Features

Package typeBlister

Dimensions & weight

Weight180 g

Questions & answers

How many cables can be connected in a row?

Lindy allows up to five 42817 cables in series, giving 25 m in total.

Does the cable need drivers?

No. It is Plug and Play and works on any computer with a USB-A port without extra software.

Does it give USB 3.0 speed?

No, the cable follows the USB 2.0 standard and transfers data at up to 480 Mbit/s even when the port and device support USB 3.0.
