When the connected devices reach the 123 W limit, the switch cuts power to the port with the lowest priority. Priority runs from port 1 down to port 8, so the most important camera or access point belongs on the first ports. If power runs short, a less critical device goes dark instead of the whole system.
A small office, retail outlet or house where up to eight PoE devices are powered from one place: cameras, Wi-Fi access points and IP phones. The combo port with an SFP slot lets you link the switch to another building or network cabinet over fibre as well.
| Brand | TP-LINK |
|---|---|
| Model name | TL-SG1210PP |
| Product colour | Black |
| Housing material | Steel |
| Fanless | Yes |
| User guide | Yes |
| IGMP snooping | Yes |
| Rack mounting | No |
| Forwarding rate | 14.88 |
| Auto-negotiation | Yes |
| MAC address table | 4000 |
| Store-and-forward | Yes |
| Operating relative humidity (H-H) | 10 - 90 |
| EAN | 4895252500349 |
| Switching capacity | 20 |
|---|---|
| Storage temperature (T-T) | -40 - 70 |
| Storage relative humidity (H-H) | 5 - 90 |
| Power over Ethernet (PoE) | Yes |
|---|---|
| Combo SFP ports quantity | 1 |
| Copper ethernet cabling technology | 100BASE-TX/10BASE-T |
| Total Power over Ethernet (PoE) budget | 123 |
| Gigabit Ethernet (copper) ports quantity | 10 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 10 |
| Power over Ethernet plus (PoE+) ports quantity | 2 |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 6 |
| Networking standards | IEEE 802.3af/IEEE 802.3at/IEEE 802.3i/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z |
|---|
| Switch type | Unmanaged |
|---|
| Power consumption (max) | 144.1 W |
|---|---|
| AC input voltage | 90 – 220 V |
| AC input frequency | 50 Hz |
| Input voltage | 53.5 V |
| Power source | DC/PoE |
| Input current | 2.43 |
| Power supply included | Yes |
| Number of power supply units | 1 |
| Operating temperature (T-T) | 0 – 40 °C |
|---|---|
| Heat dissipation | 482.17 |
| Cables included | AC |
|---|---|
| LED indicators | Yes |
| 10G support | No |
| Package type | Box |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
| Cable types supported | Cat3/Cat4/Cat5/Cat5e |
| MAC address auto-aging supported | Yes |
| Quality of Service (QoS) support | Yes |
| MAC address auto-learning supported | Yes |
| Width | 209 mm |
|---|---|
| Depth | 126 mm |
| Height | 26 mm |
There are eight PoE ports and a 123 W total budget. TP-Link gives 30 W as the maximum per PoE+ port; as long as all devices together stay under 123 W, they all run at once.
No. It is an unmanaged switch with no web interface and works as soon as the cables are connected.
No, the manufacturer does not support rack mounting. It is a compact desktop switch.
