GEMBIRD

Gembird WM-80ST-05 full-motion TV wall mount 37–80", single arm, up to 50 kg

The Gembird WM-80ST-05 is a single-arm full-motion TV wall mount for 37–80 inch TVs weighing up to 50 kg. The TV can be pulled up to 620 mm from the wall and swivelled 90° to either side.

  • Type: full-motion wall mount, single arm
  • Screen size: 37–80″
  • Maximum load: 50 kg
  • VESA: 200 × 200, 300 × 200, 300 × 300, 400 × 200, 400 × 300, 400 × 400, 600 × 400 mm
  • Movement: tilt +3° to −15°, swivel −90° to +90°, levelling ±3°, wall distance 76–620 mm
  • Extras: cable management, bubble level, mounting kit and manual included, black

Description

A single arm with a wide swivel range

Swivelling through 180° in total lets you turn the screen almost at a right angle to the wall, for example when the TV hangs in a corner or is watched from different rooms. The tilt range is 3° up and 15° down. The screen can also be rotated by ±3° so it hangs level after installation.

Who this TV mount is for

The WM-80ST-05 suits owners of a 37–80 inch TV weighing up to 50 kg with a VESA size between 200 × 200 and 600 × 400 mm. The arm reaches up to 620 mm from the wall, which leaves room to aim the screen.

Specifications

General

BrandGEMBIRD
Product colourBlack
Housing materialPlastic/Steel
ManualYes
SwivellingYes
Turn angle180
Pivot angle3 - -3
Mounting kitYes
Mounting typeWall
Tilt adjustmentYes
Cable managementYes
Tilt angle range3 - -15
Maximum VESA mount600 x 400
Minimum VESA mount200 x 200
Swivel angle range90 - -90
Sustainability complianceYes
Distance to the wall (max)620
Distance to the wall (min)76
EAN8716309127806

Display

Panel mounting interface200 x 200/300 x 200/300 x 300/400 x 200/400 x 300/400 x 400/600 x 400
Maximum screen size80
Minimum screen size37
Number of displays supported1

Storage

Maximum weight capacity50

Features

Package typeBox

Dimensions & weight

Width620 mm
Height425 mm
Weight7.3 kg
Depth (max)425

Questions & answers

Will my TV fit this mount?

Measure the distance between the four screw holes on the back of the TV in millimetres. Supported sizes are 200 × 200, 300 × 200, 300 × 300, 400 × 200, 400 × 300, 400 × 400 and 600 × 400 mm. The TV must be 37–80″ and weigh up to 50 kg.

How far from the wall does the TV sit?

76 mm when folded back and 620 mm when fully extended.

Is the installation hardware included?

Yes, a mounting kit and a manual are included. With a single-arm mount the whole load rests on one fixing point, so it is best screwed into a load-bearing wall.

Reviews

No reviews yet

Bought this product? Be the first to share your experience.

Write a review

Only verified buyers can leave reviews.
