The TV hooks onto the wall plate and automatic spring locks hold it in place. When you need to take it down, for example to change cables, the locks release with pull cords. As the mount neither tilts nor swivels, the TV always stays parallel to the wall.
The WM-90F-01 suits owners of a large TV who want it fixed securely against the wall and do not need to change its position. The screen must be 43–90″, the weight up to 70 kg and the VESA pattern one of the supported sizes.
| Brand | GEMBIRD |
|---|---|
| Product colour | Black |
| Housing material | Steel |
| Manual | Yes |
| Mounting kit | Yes |
| Mounting type | Wall |
| Easy to install | Yes |
| Tilt adjustment | No |
| Maximum VESA mount | 800 x 400 |
| Minimum VESA mount | 200 x 200 |
| EAN | 8716309126175 |
| Panel mounting interface | 200 x 200/300 x 200/300 x 300/400 x 200/400 x 300/400 x 400/600 x 400/800 x 400 |
|---|---|
| Maximum screen size | 90 |
| Minimum screen size | 43 |
| Number of displays supported | 1 |
| Maximum weight capacity | 70 |
|---|
| Package type | Box |
|---|
| Width | 431 mm |
|---|---|
| Height | 29 mm |
| Weight | 2.37 kg |
| Depth (max) | 29 |
| Depth (min) | 29 |
200 × 200, 300 × 200, 300 × 300, 400 × 200, 400 × 300, 400 × 400, 600 × 400 and 800 × 400 mm. Measure the horizontal and vertical distance between the screw holes on the back of your TV.
No. According to the manufacturer there is no tilt; the TV sits 29 mm from the wall.
Yes, the manufacturer states that all the necessary installation materials and a manual are included.
