According to the manufacturer, the 2.5 Gbit/s and 1 Gbit/s ports can each be set as WAN or LAN, so the faster port can serve a broadband line above one gigabit or, for example, a NAS. An external drive plugged into the USB 3.0 port becomes available to every device on the network, with media server, FTP and Samba support. A dual-core 1 GHz processor and OFDMA help keep things smooth when many devices are online.
Homes with an internet plan faster than 1 Gbit/s, or planning to move to one; families streaming, gaming and working on several devices at the same time; and users who may later extend coverage with a OneMesh extender and want to manage the network from a phone with the Tether app.
| Brand | TP-LINK |
|---|---|
| Product type | Desktop/pole router |
| Product colour | Black |
| DSL WAN | No |
| Firewall | Yes |
| VPN server | OpenVPN, PPTP |
| DHCP client | Yes |
| DHCP server | Yes |
| Guest access | Yes |
| Media server | Yes |
| Static route | Yes |
| Parental control | Yes |
| NAT functionality | Port Forwarding Port Triggering DMZ UPnP Virtual Server |
| Dynamic DNS (DDNS) | Yes |
| Built-in FTP server | Yes |
| WAN connection type | RJ-45 |
| DoS attack prevention | Yes |
| Quick installation guide | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Stateful Packet Inspection (SPI) | Yes |
| Operating relative humidity (H-H) | 10 - 90 |
| EAN | 4897098686775 |
| Processor cores | 2 |
|---|---|
| Processor frequency | 1000 GHz |
| Built-in processor | Yes |
| Support Samba (storage) | Yes |
|---|---|
| Storage temperature (T-T) | -40 - 70 |
| Storage relative humidity (H-H) | 5 - 90 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
|---|---|
| USB port | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 5 |
| Ethernet LAN interface type | Gigabit Ethernet |
| USB sharing | Yes |
| Ethernet WAN | Yes |
| SIM card slot | No |
| Port forwarding | Yes |
| Port triggering | Yes |
| 3G/4G USB modem compatibility | No |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (max) | 4804 Mbit/s |
| Antenna design | External |
| Networking standards | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n |
| Security algorithms | WPA/WPA2/WPA3 |
| Antenna type | 3x3 |
| Antenna included | Yes |
| Antennas quantity | 6 |
| Number of guest networks (5 GHz) | 1 |
| Network address translation (NAT) | Yes |
| Number of guest networks (2.4 GHz) | 1 |
| WLAN data transfer rate (first band) | 4804 |
| WLAN data transfer rate (second band) | 574 |
| Firewall security | SPI Firewall |
|---|
| On/off switch | Yes |
|---|---|
| Reset button | Yes |
| WPS push button | Yes |
| AC adapter included | Yes |
|---|---|
| Power source type | DC |
| High power | Yes |
| Operating temperature (T-T) | 0 – 40 °C |
|---|
| Cables included | LAN (RJ-45) |
|---|---|
| DMZ support | Yes |
| VPN support | OpenVPN, PPTP |
| Indication light | Yes |
| Quality of Service (QoS) support | Yes |
| Width | 272.5 mm |
|---|---|
| Depth | 147.2 mm |
| Height | 49.2 mm |
Yes, according to the manufacturer it supports OneMesh: together with a OneMesh extender it forms one home Wi-Fi network under a single name.
Yes. As a VPN server it supports OpenVPN and PPTP, and the manufacturer also mentions a VPN client function.
The manufacturer does not specify range. Six external antennas and beamforming, which focuses the signal towards devices, help coverage.
