TP-LINK ES205G managed switch gigabit ethernet 5-port

Switching capacity10
Power sourceAC/DC
Operating temperature (T-T)0 – 40 °C
Switch typeManaged
Width100 mm
Virtual LAN featuresMTU VLAN/Port-based VLAN/Tagged VLAN

The TP-LINK ES205G is a compact managed network switch designed to streamline data flow across your office or small business infrastructure. This 5-port gigabit ethernet switch combines ease of use with professional-grade control, making it an essential upgrade from unmanaged alternatives.

Description

Full control over your network traffic

5 Gigabit Ethernet ports deliver fast 10/100/1000 Mbps connections for all connected devices
Managed switch capability lets you monitor, configure and optimise network performance in real time
Built-in PoE support powers compatible devices directly through ethernet cables, eliminating the need for separate power supplies
Compact form factor fits neatly into standard server racks or desktop setups

This switch works best for growing businesses that need reliable connectivity between servers, workstations and IP cameras, or for professionals who demand visibility and control over their network without unnecessary complexity.

Specifications

General

Brand	TP-LINK
Model name	Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
Product colour	Black
Fanless	Yes
User guide	Yes
Jumbo frames	15
Cloud-managed	Yes
IGMP snooping	Yes
Wall mountable	Yes
Forwarding rate	7.4
Auto-negotiation	Yes
Link aggregation	Yes
MAC address table	8000
Store-and-forward	Yes
Packet buffer memory	4
Transmission distance (max)	0.25
Operating relative humidity (H-H)	10 - 90
EAN	8885020620917

Storage

Switching capacity	10
Storage temperature (T-T)	-40 - 70
Storage relative humidity (H-H)	5 - 90

Ports

Power over Ethernet (PoE)	Yes
Port mirroring	Yes
Virtual LAN features	MTU VLAN/Port-based VLAN/Tagged VLAN
Total Power over Ethernet (PoE) budget	65
Power over Ethernet (PoE) ports quantity	4
Power over Ethernet (PoE) power per port	30
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	5
Power over Ethernet plus (PoE+) ports quantity	4

Connectivity

Networking standards	IEEE 802.1ab/IEEE 802.1p/IEEE 802.1Q/IEEE 802.3at/IEEE 802.3x

Keyboard & controls

Switch type	Managed
Reset button	Yes

Battery & power

Power source	AC/DC
DC input voltage	53.5
Power supply included	Yes

Performance & capacities

Operating temperature (T-T)	0 – 40 °C

Features

LED indicators	Yes
10G support	No
Package type	Box
VLAN support	Yes
DHCP features	DHCP client
Auto MDI/MDI-X	Yes
Loop protection	Yes
Flow control support	Yes
Jumbo frames support	Yes
Quality of Service (QoS) support	Yes
