TP-Link Omada EAP653UR WiFi 6 Ceiling/Wall Access Point 3000 Mbps

  • Storage temperature (T-T)-40 - 70
  • DC voltage range12
  • Operating temperature (T-T)0 – 40 °C
  • Security algorithmsHTTPS/SNMP/SNMPv2/SNMPv3/SSH/WPA/WPA2/WPA3
  • Width160 mm
  • Ethernet LAN (RJ-45) ports1

The TP-Link Omada EAP653UR is a WiFi 6 wireless access point delivering up to 2976 Mbps combined throughput, designed for businesses that need reliable, high-capacity coverage without cluttered cabling. It mounts flush to a ceiling or wall and draws power over Ethernet, so a single cable handles both data and power.

Description

Centralised management and intelligent performance

  • WiFi 6 (802.11ax) — higher capacity, lower latency, and better performance in dense device environments compared to WiFi 5
  • PoE-powered — no separate power adapter needed, simplifying installation and cable routing
  • Ceiling and wall mounting — flexible placement suits open offices, hotel corridors, and retail floors
  • Omada SDN integration — full cloud-based centralised management, auto channel selection, and fast roaming across multiple access points from one dashboard
  • Omada Mesh support — extends coverage wirelessly to hard-to-wire areas without additional cabling

The EAP653UR suits hotels, offices, schools, and retail spaces where many devices connect simultaneously and uninterrupted roaming between access points is essential.

Specifications

General

BrandTP-LINK
Model nameEAP653 UR
Product colourWhite
5 GHzYes
6 GHzNo
SeriesOmada
SyslogYes
2.4 GHzYes
PlacementCeiling, Wall
BeamFormingYes
Mounting kitYes
Rate limitingYes
Number of users250
Quick start guideYes
Firmware upgradeableYes
Web-based managementYes
Airtime Fairness (ATF)Yes
Spread spectrum methodOFDMA
Automatic channel scanningYes
Maximum data transfer rate2976
Automatic channel selectionYes
Operating relative humidity (H-H)10 - 90
Maximum data transfer rate (5 GHz)2402
Maximum data transfer rate (2.4 GHz)574
EAN8885020620566

Storage

Storage temperature (T-T)-40 - 70
Storage relative humidity (H-H)5 - 90

Ports

Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10/100/1000
DC-in jackYes
Power over Ethernet (PoE)Yes

Connectivity

Networking standardsIEEE 802.11a/IEEE 802.11ac/IEEE 802.11b/IEEE 802.11g/IEEE 802.11h
Security algorithmsHTTPS/SNMP/SNMPv2/SNMPv3/SSH/WPA/WPA2/WPA3
MIMOYes
MIMO typeMulti User MIMO
Antenna typeInternal
Band steeringYes
Frequency band2.4 - 5

Keyboard & controls

Reset buttonYes

Battery & power

DC voltage range12
Transmitting power (CE)27
Transmitting power (FCC)22

Performance & capacities

Operating temperature (T-T)0 – 40 °C
Fit AP mode featuresMesh networking
MAC address filteringYes

Features

LED indicatorsYes
Package typeBox
VLAN supportYes
Cabling technology10/100/1000Base-T(X)
Flow control supportYes
Quality of Service (QoS) supportYes

Dimensions & weight

Width160 mm
Depth160 mm
Height33.6 mm
